Heyer Modular+ - Parts List Module 2; Connectors on Module 2; Plug Connectors on Board AVM 3-1

Repair Information
24
2.11.1 Parts list module 2
Pos. No. Description Order No.
1 Ventilator module 2, complete 460-1150
2.11.2 Connectors on module 2
2.11.2.1 Plug connectors on board AVM 3-1
Connector connected to Plug conf. Func. / Signal
X2 Module 1 28 pole communication
with module 1
Connector connected to Plug conf. Func. / Signal
X3 Module 1 14 pole communication
with module 1
Connector connected to Plug conf. Func. / Signal
X4 Module 1 10 pole communication
with module 1
Connector connected to Pin. def. Func. / Signal Color / No.
X7 PT-100 sensor X7-1 temperature dep. blue
X7-2 resistance red
Connector connected to Pin. def. Func. / Signal Color / No.
X9 Fan ventilator X9-1 +12V red
FAN pneumatic X9-2 fan control signal yellow
module X9-3 n.c.
X9-4 n.c.
X9-5 GND black
Connector connected to Pin. def. Func. / Signal Color / No.
X10 Driving gas X10-1 +12V white
Driving gas switch switch to detect X10-2 GND brown
a failure of the gas X10-3 n.c.
supply X10-4 n.c.
X10-5 n.c.
Connector connected to Pin. def. Func. / Signal Color / No.
X11 over temperature X11-1 22V
AC
when red
HTSEC switch (NC) X11-2 switch is open blue
patient X11-3 n.c.
block heating X11-4 n.c.
X11-5 n.c.
