H E Y E R P a s i t h e c
88 / 106 HEYER Pasithec, Operator’s manual Rev. 0.2 Draft - 12/09
10.3 System’s Technical Specifications
10.3.1 Gas Supply
Pipeline Supply: O
2
, N
2
O, Air
Connect to pipeline: DISS-male, DISS-female, NIST (ISO 5359)
All fittings used to connect O
2
, N
2
O and Air pipeline gas supply should
be ready.
Input pressure at pipeline
inlets:
280~600 kPa（2.8~6 bar）
WARNING: All gas supplies must be in accordance with approved medical levels.
Pressure at pipeline inlets must be 280~600 kPa when gas flow stops in the anesthetic gas delivering
system.
10.3.2 Flowmeter
Flow rate
Gas component Scale (thin tube) Scale (thick tube)
O
2
0.05~1 L/min 1.1~10 L/min
N
2
O 0.05~1 L/min 1.1~12 L/min
Air 0.05~1 L/min 1.1~15 L/min
CAUTION: Adjust O
2
and Nitrous oxide proportionally to ensure the O
2
concentration is
no less than 25%.
Accuracy: ±10% of full scale under the condition of 20°C, 101.3 kPa,
10.3.3 Classification
According to IEC60601-1, HEYER Pasithec belongs to the following classifications:
•
Class I equipment
•
Type B equipment
•
General equipment
•
Mobile equipment
•
Flammable anesthetic cannot be used
•
Operate continuously
