H E Y E R P a s i t h e c
Rev. 0.2 Draft – 12/09 HEYER Pasithec, Operator’s manual 89 / 106
10.4 Input/Output
10.4.1 Electrical
Voltage: 100~240 VAC, 50/60 Hz
Maximum input current: 10A
Fuse of AMSO:
250V/10A, ∅5X20 (F)
Socket of AMSO: 4
Fuse above AMSO:
250V/2A
，
∅5X20 (F)
Maximum output current of AMSO: 1.5A (each); 6A (total)
Earth resistance: <0.2Ω
WARNING: The connection of equipment to the auxiliary mains socket outlets can
increase the patient leakage currents to values exceeding the allowable
limits in the event of a defective protective earth conductor.
10.4.2 Pneumatic
Pipeline supply: O
2
, Air, N
2
O
Connect to pipeline: DISS-male, DISS-female, NIST (ISO 5359).
All fittings used to connect O
2
, Air and N
2
O pipeline gas
supply are all ready.
Display pressure: Color coded gauges
Connect vaporizer: Two Selectatec®-type interface vaporizers
Input pressure at pipeline inlets: 280~600kPa
Connect to Breathing System:
Insp. Port connector: ∅22 OD /∅15 ID
Exp. Port connector: ∅22 OD /∅15 ID
Breathing System to AGSS: ∅30 OD
10.5 Electromagnetic Compatibility
Changing or reassembling this equipment without authorization may cause electromagnetic
compatibility problems. Contact HEYER for assistance. Designing and testing this equipment is in
accordance with the following stipulations.
WARNING: Using cell phones or other radio equipment near this product may cause
malfunctions. Closely monitor the working condition of this equipment if
radio equipment is in close proximity.
Using other electrical equipment in this system or nearby may cause interference. Check if the
equipment works normally in these conditions before using on a patient.
Be careful of the following when HEYER Pasithec is connected:
Do not put any object which is not in accordance with EN60601-1 within 1.5 meters of patients.
An isolated transformer must be used for alternating current supply (in accordance with IEC60989).
Additional protective ground wires are equipped if all the devices (for medical or non-medical use) are
connected to Pasithec by using signal input/signal output cable.
