Rev. 0.2 Draft – 12/09 HEYER Pasithec, Operator’s manual 95 / 106
10.8.6 Monitoring Performance
Item Range Resolution Accuracy
V
T
0 ~ 3000 ml 1 ml Child: ±10%, at least 10 ml;
Adult: ±10%
MV 0.1 ~ 30 L 0.1 L ±15%
Freq. 0 ~ 110 bpm 1 bpm
±1 bpm
PEAK -20 ~ 99 cmH
2
O 1 cmH
2
O ±5% ， at least 1 cmH
2
O
MEAN -20 ~ 99 cmH
2
O 1 cmH
2
O ±5% ， at least 1 cmH
2
O
PLAT -20 ~ 99 cmH
2
O 1 cmH
2
O ±5% ， at least 1 cmH
2
O
FiO
2
18 ~ 100 ％ 1% ±3 ％
C 0~100 ml/cmH
2
O 1 ml/cmH
2
O
±2 ml/hPa (≤10mL/hPa) ； ±20% (other)
PEEP -20 ~ 99 cmH
2
O 1 cmH
2
O
±2 cmH
2
O
Battery capacity indication: 100%, 75%, 50%, 25%, 0%.
When using the battery, the icon displays the remainder battery
capacity; when connected with the AC, the icon displays charging.
Paw-t waveform: Pressure monitoring range: 0 to 80 cmH
2
O. Paw-t waveform display
pressure axis varies with the upper alarm limit of Paw:
Range Gain
0 to 10 cmH
2
O 5 cmH
2
O
0 to 30 cmH
2
O 10 cmH
2
O
0 to 80 cmH
2
O 20 cmH
2
O
Time axis is not only a fixed range but also same scale for Flow-t and
Paw-t waveforms.
Range: 0 to 15 seconds (gas module open).
Range: 0 to 20 seconds (gas module close).
Flow-t waveform: Flow scale: -90 to 90 L/min; gain: 45 L/min. Time scale: 0 to 15 s (gas
module open); 0 to 20 s (gas module close).
CO
2
-t waveform ： CO
2
scale: 0 ~ 76 mmHg; gain: 38 mmHg. Time scale: 0 to 15 s (gas
module open); 0 to 20 s (gas module close).
Pressure-Volume loop: X-Axis: pressure; fixed range: -20 to 80 cmH
2
O; gain: 20 cmH
2
O.
Y-Axis: tidal volume; fixed range: 0 to 1500 ml; gain: 250 ml.
Flow-Volume loop: X-Axis: tidal volume; fixed range: -1400 to 0 ml/min; gain: 700 ml.
Y-Axis: flow; fixed range: -90 to 90 ml; gain: 45 ml.
