1) Select a virtual panel. Up to 4 virtual panels are selectable.
2) Set Time Threshold, and Sensivity.
Time Threshold
The me an object loiter in the region. When the duraon of the object in the dened
detecon area exceeds the threshold, the device will trigger an alarm.
Sensivity
Sensivity
is the object size which is able to trigger an alarm. The higher the sensivity is,
the more easily the detecon alarm will be triggered.
3) Click Draw Area.
4) Draw a quadrilateral in the preview window.
7.
Oponal: Draw the maximum size/minimum size for targets.
Note
Only the targets in the size ranging from maximum size to minimum size will trigger Intrusion
detecon.
1) Click Max. Size/Min. Size.
2) Draw an area in preview window.
3) Click Stop Drawing.
8.
Oponal: Select Detecon Target as Human or Vehicle to discard alarms which are not triggered
by human body or vehicle.
9. Set the arming schedule. Refer to
Congure Arming Schedule .
10. Set linkage acons. Refer to Congure Linkage Acons .
11. Click Apply.
6.2.7 Region Entrance
Detecon
Region entrance detecon detects objects that enter a predened virtual region.
Steps
1. Go to Smart Analysis → Smart Event Sengs → Perimeter Protecon .
2. Select a camera.
3. Click Region Entrance
Detecon.
Network Video Recorder User Manual
57
