6.5 Transferring Data to a PC (USB Drive Mode)
140
Data saved to a CF card can be transferred to a PC using the supplied USB cable.
Before connecting the USB cable to the HiLogger, set the communications inter-
face setting to USB (p. 170), and select “USB Drive Mo
de” on the HiLogger.
6.5 Transferring Data to a PC (USB Drive Mode)
• Refer to the Logger Utility Instruction Manual (on the supplied CD) to
observe data using the Logger Utility program on a PC
(p. 187).
• Data cannot be read from a USB flash drive in the HiLogger. To load files
f
rom a USB flash drive removed from the HiLogger, insert it into a USB
slot on the PC.
• USB Drive Mode is not available with Windows 2000.
Select the USB Drive Mode
Select the [System] Screen.
Select [USB Drive Mode].
Apply
A confirmation dialog appears.
1
2
3
Select [Yes].
Apply
The USB Drive Mode is enabled.
4
Connect the USB cable (p. 141).
No other HiLogger operations are available
when the USB Drive Mode is
enabled. Also, HiLogger communications
with the supplied Logger Utility program
are disabled.
See: "To exit USB Drive Mode" (p .141)

Hioki LR8401-20 Specifications

General

Type	Data Logger
Model	LR8401-20
Number of channels	20
Display	LCD
Power Supply	AC adapter or battery
Input Type	Voltage, Thermocouple, Resistance
Sampling Rate	100 ms to 1 hr
Communication Interface	USB
Accuracy	±0.1% of reading
Operating Temperature	0°C to 50°C
Pulse Input	No
Measurement Range (Temperature)	-200 to 1372 °C (K), -200 to 400 °C (T), -200 to 1000 °C (E), 0 to 1768 °C (R), 0 to 1768 °C (S), 0 to 1820 °C (B), -100 to 400 °C (N), -200 to 400 °C (J)
Recording Interval	100 ms to 1 hr
