3.7 Entering Titles and Comments (as needed)
71
3
3
Chapter 3 Settings
Comments of up to 40 characters can be entered as a title for the measurement
data, and as a label for each input waveform.Titles and comments are displayed on
the waveform/numerical screen (Comments appear only when [Value+Cmnt] dis-
play is selected).
Titles can be entered on the [S
etting] and [Comment] screens, and comments can
be entered on the [CH] and [Comment] screens.
This description enters a comment on the [CH] sc
reen.
3.7 Entering Titles and Comments (as needed)
The Setting screen cannot be displayed while measuring.
Select the [CH] screen.
Select the field to enter
the comment.
1
2
Apply
The character entry screen
appears.
3
Select the characters to
enter
To enter a space, select a
blank character.
Apply
Characters appear in the en-
try field as you select them.
Entry field
Navigate the entry fieldFinished with entry
