7.3 Displaying detailed trends
102
Displayed items
Displayed channel
Changing the displayed items and displayed channel
Settings:( : Default)
Urms1/2
RMS voltage refreshed each half-cycle
Irms1/2
RMS current refreshed each half-cycle
(inrush current)
Freq_wav
One frequency cycle
S(t)
Instantaneous flicker value
Display the
pull-down menu
Select a setting
Accept the setting
Cancel
[SELECT]
Select
S(t) is only displayed when [Flicker] is set to [Pst, Plt].
Settings:( : Default)
CH1/ CH2/ CH3/ CH4
To Next Page
