Left side
AC adapter connection jack
Connect the included Z1002 AC Adapter
here.
See: (p.32)
Power switch
Turns the instrument on and off.
See: (p.36)
Power ON
Power OFF
CHARGE LED
Lights up while the Z1003 Bat-
tery Pack is charging.
See: (p.30)
Strap eyelet
See: (p.28)
AC adapter hook
Loop the AC adapter cord through this hook.
See: (p.32)
Air vents
Do not block these vents.
See: (p.6)
Back
Label
Contains important warnings as well
as the CE mark, country of manufac-
ture, and manufacturer.
Serial No.
Displays the instrument's serial number. Do
not remove the label as the information is
contains is necessary in order to manage the
device.
MAC address label
Displays the instrument's unique MAC
address, which is used when configuring
a LAN connection. Do not remove the la-
bel as the information it contains is nec-
essary in order to manage the device.
Battery compartment
Install the included Z1003 Battery Pack
here.
See: (p.30)
