1.2 Names and Functions of Parts
24
Multiplexer Unit Slot
(RM3545-02 only)
Installing the Z3003 Multiplexer Unit
(up to 2 units) (p.42)
Using the Multiplexer Unit
RM3545-02
Bottom Panel
Stand
When using the stand
Extend the legs all the way. Do not extend partially.
Make sure to extend both legs of the stand.
Collapsing the stand
Do not collapse the stand partway. Be sure to collapse
it all the way.
This instrument can be rack mounted.
See: "Appendix 17 Rack Mounting" (p. A35)
Parts removed from this instrument should be
stored in a safe place to enable future reuse.
Do not apply heavy downward pressure
with the stand extended. The stand could
be damaged.
