Hisun HS400 - Electrical Specifications

Specifications
2-14
Electrical Specifications
Item
Metric
Standard
Service Wear
Limit
Voltage
12 V
C.D.I.
(ECU)
Operating voltage range
Overvoltage protection
Stand by current
Ignition Capacitor
8~16 V
26±2 V
≤50mA
2.2μF
Ignition coil
Minimum spark gap
Primary winding resistance
Secondary winding
resistance
6 mm (0.24in)
0.18 ~ 0.28 Ω at 20 °C (68 °F)
6.32 ~ 9.48 k Ω at 20 °C (68 °F)
Spark plug cap
Resistance 4.5~5.5 k Ω
Rectifier/regulator
Regulation voltage
Battery protection voltage
14.5±0.5 V
≤15 V
Battery
Specific gravity Gel battery
Circuit breaker
Type
Main fuse
Lighting system fuse
Ignition fuse
Auxiliary DC jack fuse
Four-wheel drive fuse
Signaling system fuse
Backup fuse(odometer)
Reserve
Reserve
Reserve
Reserve
Fuse
30 A×1
15 A×1
10 A×1
10 A×1
5 A×1
10 A×1
10 A×1
30 A×1
15 A×1
10 A×1
5 A×1
Radiator fan
Running rpm
2,950 r/min
