Hisun HS400 - Engine Oil

Maintenance and Adjustment
3-8
CHECKING THE ENGINE OIL LEVEL
1. Remove the seat.
2. Check the engine oil level on the dip
stick (1). The oil level should be
between the Maximum (2) and
minimum (3) level marks on the dip
stick.
Note:
Do not screw in the dip stick when
checking the level, it is done with the
dip stick resting on the threads.
Recommended oil
Note:
Recommended oil classification:
API Service “SE”, “SF”, “SG” type or
equivalent (e.g. “SF—SE—CC”, “SF—
SE—SD” etc.)
3. Start the engine and allow it to
warm up for several minutes.
4. Stop the engine and recheck the oil
level. Add oil if necessary to
achieve the proper level.
CHANGING THE ENGINE OIL
Place the vehicle on a level surface.
1. Start the engine and let it warm up
for several minutes.
2. Stop the engine and place an oil
pan under the engine oil drain bolt
(2).
3. Remove: driver’s seat, passenger’s
seat.
4. Remove: engine oil dipstick
(1)engine oil drain bolt (2) Drain the
engine oil from the crankcase.
