General
1-19
Snap Ring Pliers
Snap ring pliers are specialized pliers
with tips that fit into the ends of snap
rings to remove and install them.
Warning:
Snap rings can slip and fly off when
removing and installing them. Also,
the snap ring pliers tips may break.
Always wear eye protection when
using snap ring pliers.
Snap ring pliers (Figure 17) are
available with a fixed action (either
internal or external ) or convertible (one
tool works on both internal and external
snap rings). They may have fixed tips or
interchangeable ones of various sizes
and angles. For general use, select a
convertible type snap ring plier with
interchangeable tips (Figure 17).
Hammers
Various types of hammers are available
to fit a number of applications. Use a
ball-peen hammer to strike another tool,
such as a punch or chisel.
Use soft-faced hammers when a metal object
must be/struck without damaging it. Never
use a metal-faced hammer on engine and
suspension components because damage
occurs in most cases. Always wear eye
protection when using hammers. Make sure
the hammer face is in good condition and the
handle is not cracked. Select the correct
hammer for the job and make sure to strike
the object squarely. Do not use the handle or
the side of the hammer to strike an object.
Ignition Grounding Tool
Some test procedures require turning the
engine over without starting it. To prevent
damage to the ignition system from excessive
resistance or the possibility of fuel vapor
being ignited by an open
spark, remove the spark plug cap and ground
it directly to a good engine ground with the
tool shown in (Figure 18).
Make the tool shown from a No.6 screw and
nut, two washers, length of tubing, alligator
clip, an electrical eyelet and a length of wire.
