Maintenance and Adjustment
3-20
R Rear
4. Place the other end of the hose into a
container.
5. Slowly apply the brake pedal several times.
6. Push down on the pedal and hold it.
7. Loosen the bleed screw and allow the pedal
to travel towards its limit.
8. Tighten the bleed screw when the pedal limit
has been reached, then release the pedal.
9. Repeat steps (5) to (8) until all the air bubbles
have disappeared from the fluid.
10. Tighten the bleed screw.
11. Add brake fluid to the proper level.
Warning:
Check the operation of the brake after
bleeding the brake system.
ADJUSTING THE SELECT LEVER SHIFT ROD
Forward (1)
Neutral (2)
Reverse (3
Select Lever shift rod (4)
Plastic cover (5)
Both Lock Nuts (6)
Warning:
Before shifting, you must stop
the vehicle and take your foot
off the accelerator pedal.
Otherwise, the transmission
may be damaged
1. Make sure the select
lever is in NEUTRAL.
2. Loosen both locknuts (6).
Note:
The select lever shift rod
locknut (select lever side) has
left-handed threads. To loosen
the locknut , turn it clockwise.
3. Tighten the lock nuts (6).
