69
Camber Mixing (GLID Only) cont.
10. Scroll to highlight the “FLAP” eld and press the jog dial to
activate the menu.
11. Rotate the jog dial to input the desired travel for the “FLAP”
servo when camber is active. Press the jog dial to conrm
your input.
12. If the model has a second ap servo, repeat step 11 in the
“FLP2” eld.
15. Scroll to the “S/W” eld and press the jog dial twice to
activate the menu.
13. Scroll to highlight the “SPEED” eld and press the jog dial to
activate the menu.
14. Scroll to dene the amount of time (0.0 to 10.0 seconds) for
the camber settings to fully deploy. Press the jog dial to
conrm your selection.
b. If you choose a switch:
- The switch position menu will appear. Scroll to highlight
the switch position that you will use to enable the mix.
Press the jog dial to conrm your selection.
16. Scroll to select a switch to activate the camber mix. Press the jog dial to conrm your selection.
a. If you choose the “NULL” option, the mix will remain inactive at all times for this model.
- Scroll to select “ON” and press the jog dial to conrm your
selection. If you toggle the selected switch, the eld in the
top right corner of the screen will indicate when the mix
is active.
c. If you choose “Cond” (Flight Condition):
- The upper right eld of the menu displays which ight
condition is currently active and will be programmed.
- Scroll to the Flight Condition eld and press the jog dial to
activate the menu.
- Choose the desired ight condition and press the jog dial
to conrm your selection.
