83
Throttle Cut cont.
6. Scroll to highlight “S/W” and press the jog dial to activate the
switch menu.
7. Scroll to select a switch to activate the camber mix. Press the
jog dial to conrm your selection.
- Scroll to select “ON” and press the jog dial to conrm your selection. If you toggle the selected
switch, the eld in the top right corner of the screen will indicate when the mix is active.
8. Press the Back button to return to the Model Function menu.
To disable Throttle Cut:
1. Scroll to highlight the “MIX” eld in the Throttle Cut menu
and press the jog dial to activate the menu.
2. Select “INH” (inhibit) and press the jog dial to conrm your
selection.
3. Press the Back button to return to the Model Function menu.
4. Scroll to the “POS” (position) eld and press the jog button to
activate the menu.
5. Rotate the jog dial to input the desired position of the throttle
servo when throttle cut is activated. Models will typically
require negative values to set a “kill engine” position. Ensure
that the selected position does not cause the throttle servo to
bind or place stress on the carburetor’s control arm.
The momentary “deadman” switch (Switch-F) is a convenient and commonly-used throttle cut
switch. Throttle cut should be o when the switch is in its neutral position.
Throttle Hold
Throttle hold is used to set the throttle at a programmed position while still allowing the throttle stick to
control blade pitch. This function is often used to facilitate auto-rotation maneuvers.
The throttle hold feature will not work unless a hold position has been assigned a switch using
the ight condition/idle-up function as was done on page 57.
a. If you choose the “NULL” option, throttle cut will remain
inactive at all times for this model.
b. If you choose a switch:
- The switch position menu will appear. Scroll to highlight
the switch position that you will use to enable throttle cut.
Press the jog dial to conrm your selection.
