65
Aileron to Rudder Mixing cont.
c. If you choose “Cond” (Flight Condition):
- The upper right eld of the menu displays which ight
condition is currently active and will be programmed.
- Scroll to the Flight Condition eld and press the jog dial to
activate the menu.
- Choose the desired ight condition and press the jog dial to conrm your selection.
- Repeat steps 4-12 to dene the settings for each ight condition.
15. Press the back button to return to the model function menu.
To disable the aileron-rudder mix:
1. Scroll to highlight the “MIX” eld in the aileron-rudder mix
menu and press the jog dial to activate the menu.
2. Select “INH” (inhibit) and press the jog dial to conrm your
selection.
3. Press the back button to return to the model function menu.
You may also select a ight condition in this menu by activating the desired ight condition.
Elevator to Camber Mixing
The Elevator-to-Camber Mix allows the model to drop and raise the trailing edge of the wing control
surfaces in conjunction with elevator inputs. This function is not valid for the “1AILE” or “ELEVON” wing
types unless aps are also present. If using a “1AILE + 1FLAP”, “1AILE + 2FLAP”, “ELEVON + 1FLP”, or
“ELEVON + 2FLP” wing type, do not congure any settings for the “AILE” function. Congure only ap
servo movements.
To congure an elevator-to-camber mix:
1. From the model menu, rotate the jog dial to highlight
“ELEV>CAMB” and press the jog dial once to enter the
activation menu.
4. Scroll to the function eld (“AILE” or “FLAP”). If “AILE” is not
the current function, press the jog dial to activate the menu.
Otherwise, skip to step 7.
5. Scroll to select “AILE” and press the jog dial to conrm your
selection.
2. Press the jog dial again to activate the menu.
3. Rotate the jog dial to select “ACT” (activate), then press the jog
dial to conrm your selection and activate the elevator-to-
camber mix menu.
