98
RPM cont.
3. Scroll to select “Prop-M” using the magnetic RPM sensor. If
using an optical sensor, select “Prop-2”, “Prop-3” or “Prop-4”.
The numeral indicates the number of blades on your propeller.
Press the jog dial to conrm your selection.
1. From the sensor menu, rotate the jog dial to highlight “TEMP”
and press the jog dial once to enter the temperature menu.
2. Press the jog dial again to activate the “UNIT” eld.
3. Scroll to select “°F” or “°C”. Choose °F to receive temperature in
degrees Fahrenheit, and °C for degrees Celsius. Press the jog
dial to conrm your selection.
4. Press the back button to return to the sensor menu.
4. If you are using a second RPM sensor, repeat steps 2 and 3 on the lower “UNIT” eld.
5. Press the back button to return to the sensor menu.
Temperature
The TEMP screen displays temperature readings from as many as four separate temperature sensors. An
additional eld (H.TEM) displays the highest temperature recorded during the ight.
Required Sensor: HTS-TEMP Temperature Sensor or HTS-eTEMP Engine Temperature Sensor.
Battery
The Battery screen displays the voltage of the receiver battery (no sensor is required for this data).
Additionally, this screen displays ight pack voltage, motor current, and motor wattage for electric-
powered models.
Required Sensor: HTS-C50 50-Amp Current Sensor or HTS-C200 200-Amp Current Sensor.
Receiver battery voltage is also displayed on the lower right corner of the Flash 7 home screen.
