7 Channel 2.4 GHz Aircraft Computer Radio System
7 Channel 2.4 GHz Aircraft Computer Radio System
Section 5: Acro and Glider Programming Menu
75
Butterfly Mixing (GLID Only) cont.
- Scroll to select the middle value eld and press the jog dial to
activate the menu.
20. Press the back button four times to return to the model
function menu.
To disable buttery:
1. Scroll to highlight the “MIX” eld in the buttery menu and
press the jog dial to activate the menu.
2. Select “INH” (inhibit) and press the jog dial to conrm your
selection.
3. Press the back button to return to the model function menu.
Gyro
It is often desirable to use a gyro to help stabilize one or more ight axis on xed-wing models. The Flash
7 provides up to three gyro sensitivity settings per model memory. The gyro setting can also be specied
for each dened ight condition.
The GYRO function must be assigned to a channel before this option will appear in the Model
function menu. See Section 3 for instructions regarding the Channel menu.
1. From the model menu, rotate the jog dial to highlight “GYRO”
and press the jog dial once to enter the activation menu.
2. Press the jog dial again to activate the menu.
3. Rotate the jog dial to select “ACT” (activate), then press the jog
dial to conrm your selection and activate the gyro menu.
4. Scroll to the “RATE” eld and press the jog button to activate
the menu.
5. Scroll to dial in the desired amount of gyro gain (consult the
gyro manufacturer’s instructions for guidance).
- Rotate the jog dial to position the top of the bar graph at the
throttle position where the mix will be enabled. As you move
the throttle stick, the eld in the top right corner of the screen
will indicate when the mix is active.
To Next Page
