Butterfly Mixing (GLID Only) cont.
16. Scroll to the “S/W” eld and press the jog dial twice to
activate the menu.
17. Scroll to select a switch to activate the buttery mix. Press
the jog dial to conrm your selection.
a. If you choose the “NULL” option, the buttery mix will
remain inactive at all times for this model.
b. If you choose a switch:
- The switch position menu will appear. Scroll to highlight the
switch position that you will use to enable the mix. Press the
jog dial to conrm your selection.
- Scroll to select “ON” and press the jog dial to conrm your
selection. If you toggle the selected switch, the eld in the top
right corner of the screen will indicate when the mix is active.
18. Scroll to highlight the “T.STICK” eld and press the jog dial to
activate the menu.
19. Scroll to select the movement type for the throttle stick.
Press the jog dial to conrm your selection.
The SPEED value is ignored when linear movement is selected.
b. If you choose “DIV.” (divided), the mix will be applied fully
when the throttle position crosses a dened threshold:
a. If you choose “LINE” (linear) the mix will be applied
proportionally to throttle position. For fully linear
movement, verify that the throttle position menu shows
the mix to be on at both ends of the throttle range, and the
middle value is “100”.
- The throttle position menu will appear. Scroll to highlight
the throttle position that you will use to enable the mix.
Press the jog dial to conrm your selection.
- Scroll to select “ON” and press the jog dial to conrm your
selection.
To Next Page
