92
Throttle Curve cont.
3. Rotate the jog dial to select ACT (activate), then press the jog
dial to conrm your selection and activate the throttle curve
menu.
2. Press the jog dial again to activate the menu.
7. Scroll to the “EXP” (exponential) eld and press the jog button
to activate the menu.
8. Rotate the jog dial to select “OFF” or “ON”. When “ON” is
selected, the points in the curve are connected with
exponential curves. Otherwise, the points are joined linearly.
Press the jog dial to conrm your selection.
4. Scroll to the “1” eld and press the jog button to activate the
menu.
5. Rotate the jog dial to input the desired throttle position at this
point on the curve (Throttle stick full down).
9. Scroll to highlight “S/W” and press the jog dial to activate the
switch menu.
10. Scroll to select a switch to activate the camber mix. Press the
jog dial to conrm your selection.
a. If you choose the “NULL” option, the set throttle curve will
remain active at all times for this model.
b. If you choose a switch:
- The current switch position will be displayed in the top
right eld of the display as “0”, “1”, or “2”.
- Repeat steps 4-8 to dene throttle curve for every switch
position.
c. If you choose “Cond” (Flight Condition):
- The upper right eld of the menu displays which ight
condition is currently active and will be programmed.
6. Repeat steps 4 and 5 for the remaining four steps on the throttle curve. As values are changed, the on-
screen graph displays real-time updates to the throttle curve.
