10 User Manual Compact Crane C10
Centre of gravity Under the lifting hook on the top of the
boom and 950 mm from underside of
crawler track.
Technical data C10
Transport length without jib 3,900 mm
Transport length with jib 4,100 mm
Transport width 800 mm
Transport height 1,930 mm
Max. space outriggers extended at 45° 4,578 x 4,578 mm
Total weight incl. jib and any ballast 4,700 kg
Total weight jib 220 kg
Total weight jib tube 24 kg
Total weight ballast 1320 kg
Weight of winch weight with hook 33 kg
Weight of winch head 16 kg
Weight 30° section 16 kg
Maximum ground pressure per surface area 26 kg/cm
2
Maximum outrigger pressure per outrigger 5,200 kg
Max. load jib horizontal retracted 1,200 kg
Max. load jib horizontal extended 575 kg
Max. load 30° section and winch head 4,000 kg
Max. winch load 1,000 kg
Max. reeving 1x reeving 2000 kg
2x reeving 4000 kg
