GENERAL DISCRIPTION
U.C10.00.00.EN Version 2.0 9
1 Crane column 11 Track undercarriage
2 Boom 1 12 Turntable
3 Extension jib 2 to 5 13 Drawbar eye
4 Jib 14 Storage box
7 Extendable stabiliser leg 17 Storage location winch head + 30° section
8 400V machine power supply on RR outrigger 18 Storage location hoist block and ballast support
9 Electrical cabinet 19 Storage location outrigger pads
10 Powerpack
20 Compact crane lifting point
2.2.1 Technical specifications
The technical data for the compact cranes are shown below.
General data
Machine brand Hoeflon
Serial number 03 12 1089 C10 (1089=service number)
Jib weight 220 kg
Maximum slope angle 15 °
Clearance angle 24 °
Max. lean angle with outriggers
5 °
Ground clearance 150 mm
Diesel engine Yanmar 3 cylinder 7.3 kW
Electric motor 400V 50 Hz 5.5 kW
Fuel tank volume Yanmar 20 L
Engine oil volume Yanmar 2.7 L
Battery 12 V, 44 Ah
Ambient temperature -10 to 40 °C
Slewing angle 360 °
Maximum working load crane See load table provided in the annexes
Maximum wind speed 10.8 (6 Beaufort) m/s
