6.7.7 Attachment winch weight
DANGER!
Max. winch load is 1000 kg, 2000 kg with single reeving and 4000
kg with double reeving. When a reeved cable is used, it is
prohibited to lift if the winch cables are twisted.
Make sure the cable runs through the grooves in the cable
sheaves and the slot in the winch head stop plate!
The winch will stop automatically when there are 3 rotations of
steel cable remaining on the winch drum.
DANGER!
WARNING!
Preparation
 Make sure the machine is supported on the outriggers, with the tracks just above the ground.
 Make sure the winch head is mounted as described (see section 6.7.1).
Attaching winch weight without reeving
 Remove the split pin from the winch weight.
 Take off the front half of the winch weight.
 Remove the two cable sheaves.
 Remove the lifting hook with the centring bush.
 Refit the lifting hook without the centring bush.
 Attach the winch cable eye to the shaft on which the cable sheaves were fitted.
 Fit the front half of the winch weight back in position. Note: the front half must be turned around before it is
put in place again. It will now slide the rest of the way over the strips, and the eye of the winch cable will fit
nicely in between.
 Fit the split pin in the 2nd hole in front of the front section of the winch weight so it is secured in place.
 Set the winch ratio to 1:1 on the remote control.
Attaching winch weight with single reeving
 Remove the split pin from the winch weight.
 Take off the front half of the winch weight.
 Remove one cable sheave.
 Remove the lifting hook with the centring bush.
 Refit the lifting hook without the centring bush.
 Attach the winch cable to the cable roller.
 Fit the front half of the winch weight back in position. Note: the front half must be turned around before it is
put in place again. It will now slide the rest of the way over the strips and almost contact the cable roller.
 Fit the split pin in the 2nd hole in front of the front section of the winch weight so it is secured in place.
 Pull the cable eye of the winch cable along the inside of the winch head and place it over the black plastic
with the hole in it. Remove the pin at the top of the winch head and fit it again with the pin through the
cable eye.
 Set the winch ratio to 1:2 on the remote control.
Attaching winch weight with double reeving
 Remove the split pin from the winch weight.
 Take off the front half of the winch weight.
