52 User Manual Compact Crane C10
6.7.6 Limits
Figure 70: 30 degree adjustable section raised Figure 71: 30 degree adjustable section lowered
USE WITHOUT JIB USE WITH JIB
Number of
reevings
Min. boom
angle
Max. boom angle Min. jib
angle
Max. jib
angle
Winch head without
lifting weight
Not
permitted
Not permitted Not
permitte
d
Not
permitte
d
Winch head 0 0 degrees 70 degrees -70
degrees
70
degrees
1 or 2 0 degrees 45 degrees -70
degrees
45
degrees
30° adjustable section
with winch head facing
down (see Figur 71).
0 0 degrees 85 degrees -40
degrees
70
degrees
1 or 2 0 degrees,
85 degrees, 80 degrees with
retracted boom
-70
degrees
60
degrees
30° adjustable section
with winch head facing
up (see Figur 70).
0 0 degrees 60 degrees -70
degrees
60
degrees
1 or 2 0 degrees 35 degrees -70
degrees
35
degrees
