20 User Manual Compact Crane C10
Figure 4: Emergency control Figure 5: Emergency control Figure 6: Emergency control
5.5 Pictograms
The pictograms used are shown below. These may not be removed. Missing or damaged pictograms must be
replaced immediately!
Pictogram Meaning Location
Use of safety shoes,
gloves and safety helmet
is mandatory.
On electrical cabinet
Lifting point for lifting the
machine.
On boom
L to R: Do not use in the
vicinity of high voltage
cables; Suspended load;
It is prohibited to be
under the load.
On the crane
It is prohibited for
unauthorised persons to
be within the working
range or DANGER ZONE
of the machine.
On the cover of the electrical cabinet
Check that all safety
devices are installed
correctly before starting
up the machine.
On the cover of the electrical cabinet
