78 User Manual Compact Crane C10
TRANSPORT, STORAGE,
DISPOSAL
8.1 Transport
8.1.1 General
WARNING!
Only use suitable lifting accessories with the correct capacity for
the lifting application. The lifting accessories must be
accompanied by a certificate, have a periodic inspection, be
visually inspected and have been found to be suitable for use.
WARNING!
The clearance angle of the loading ramps must not exceed 15
degrees.
WARNING!
When transporting the compact crane, make sure the crane is in
transport mode and that any load is removed: no load on the
hook, outriggers stowed and secured, and boom retracted.
Make sure the outriggers are fully retracted and locked in position and that the crane is fully collapsed.
There must not be any load on the compact crane.
Use loading ramps of sufficient size and capacity. The loading ramps must
be long enough so that the angle with the ground is less than 15°.
Drive the machine forwards onto a means of transport intended for this
purpose in the way described in section 6.4; when driving the machine up
the ramps the operator must be assisted by a person who provides
instructions concerning the driving direction.
Stop the motor/engine as described in section 6.4.
Set the switch on the electrical cabinet to position '0’. Remove any loose
parts from the machine. Figure: 103
Secure the machine by attaching four lashing straps to the round holes in the outrigger
leg pivots (see figure 103).
Make sure the outriggers are fully retracted and locked in position and that
the crane is fully collapsed.
There must not be any load on the compact crane.
