SAFETY
U.C10.00.00.EN Version 2.0 21
Pictogram Meaning Location
Always consult the user
manual before taking any
action.
On the cover of the electrical cabinet
Attention: Raising and
lowering outriggers.
On the outriggers
Attention: When the
green lamp is on, the
radio remote control for
the crane is active.
On crane column next to warning light
Risk of cutting or
severing
On the crane at pivot points and on
the outrigger legs at the cylinders
Electrical danger On electrical cabinet
Risk of trapping hands. On the ballast
Warning for radio remote
control.
On superstructure electrical cabinet
