76 User Manual Compact Crane C10
 Unscrew the coil on the valve (see figure 96) and swap the plug with a plug
from the emergency control (see figure 91). Once this plug is attached, the
coil with plug can be reattached.
Figure: 96
Figure: 97
 Screw the control lever (see figure 91) in the valve this is to be operated (see
figure 98).
Figure: 98
 Remove the protective cap from the start assistance terminals (see figure 99).
Figure: 99
 Place the red clamp on the start assistance terminal with the red protective
cap, and place the black clamp on the start assistance terminal with the black
protective cap (see figure 100).
Figure: 100
