10-39
4) Connect the oil tube to the cylinder head cover by aligning
the projection on the oil tube with the projection on the
cylinder head cover.
Check that the oil tube is inserted in the cylinder head cover
securely.
5) Set the tube clip D32.5 with the lugs in the position shown.
[4]
OIL TUBE
[1]
CYLINDER HEAD
COVER
[3]
TUBE CLIP
D32.5
[5]
LUGS
[2]
PROJECTIONS
