Honda BF135A - Ecm;Pgm-Fi Main Relay;Fuse Box

18-19
3. ECM/PGM-FI MAIN RELAY/FUSE BOX
a. ELECTRIC PART COVER/ECM REMOVAL/INSTALLATON
Remove the following parts.
– Engine cover (P. 4-2)
– R. engine under cover (P. 4-9)
On installation, position each connector and harness in the proper position (P. 2-48).
[1]
ELECTRIC
PART COVER
[5]
ECM (ELECTRONIC
CONTROL MODULE)
[4]
ECM CONNECTOR B
(34P CONNECTOR)
[3]
ECM CONNECTOR A
(26P CONNECTOR)
[2]
ECM CONNECTOR
C (6P CONNECTOR)
6 x 20 (2)
