1. SPECIFICATIONS 2. DIMENSIONAL DRAWINGS
1.SPECIFICATIONS
1. SPECIFICATIONS
• DIMENSIONS AND WEIGHTS
Model BF135A
Description code BARJ BASJ BARJ BASJ
Types LC LD LCD XC XD XCC XCD
Overall length 845 mm (33.3 in)
Overall width 580 mm (22.8 in)
Overall height 1,665 mm (65.6 in) 1,790 mm (70.5 in)
Dry weight (*1) 220 kg (485 lbs) 223 kg (492 lbs) 226 kg (498 lbs)
Operating weight (including oil) 228 kg (503 lbs) 231 kg (509 lbs) 234 kg (516 lbs)
*1: With propeller mounted.
Model BF150A
Description code BANJ BAPJ BANJ BAPJ
Types LC LD LCD XC XD XCC XCD
Overall length 845 mm (33.3 in)
Overall width 580 mm (22.8 in)
Overall height 1,665 mm (65.6 in) 1,790 mm (70.5 in)
Dry weight (*1) 220 kg (485 lbs) 223 kg (492 lbs) 226 kg (498 lbs)
Operating weight (including oil) 228 kg (503 lbs) 231 kg (509 lbs) 234 kg (516 lbs)
Model BF135A•BF150A
Types LC LD LCD XC XD XCC XCD
Transom height (*1) 508 mm (20.0 in) 635 mm (25.0 in)
Tilting angle 72°
Tilting stage Stageless
Swivel angle 30° right and left
Trim angle – 4° to 16°
*1: With propeller mounted.
• FRAME
*2: Transom angle is at 12°.
