Honda BF135A - Mounting Case

15-2
1. MOUNTING CASE
a. REMOVAL
Remove the following parts.
– Engine cover (P. 4-2)
– L./R. engine under covers (P. 4-9)
– Under cover front bracket (P. 4-20)
– Water relief tube C (P. 8-6)
– Engine assembly (P. 7-2)
Remove the two 12 mm self-locking nuts and remove the mounting case assembly.
[1]
12 mm SELF-LOCKING
NUT (2)
[2]
MOUNTING CASE
ASSEMBLY
