Honda BF135A - Oil Pump

11-6
2. OIL PUMP
a. REMOVAL
1) Remove the engine from the outboard motor (P. 7-2).
2) Remove the five 8 x 32 mm flange bolts. Remove the oil pump body assembly, oil pump body gasket, 14 x 20 mm
dowel pin and the 10 x 16 mm dowel pin.
Replace the oil pump body gasket with a new one on assembly.
8 x 32 (5)
[2]
14 x 20 mm
DOWEL PIN
[3]
10 x 16 mm
DOWEL PIN
[1]
OIL PUMP BODY
ASSEMBLY
[4]
OIL PUMP BODY
GASKET
