Honda BF135A - Page 79

2-69
[3] SPEED SENSOR
TUBE A
[3]
SPEED SENSOR
TUBE A
[4]
UNDERCASE
GROMMET C
[2] FUEL TUBE A
[2]
FUEL TUBE A
[1] 4 x 7 x 160 mm VINYL TUBE
[8] 3.5 x 430 mm FUEL TUBE
Set in the recess in the
under cover front bracket.
[5]
4 x 7 x 160 mm VINYL
TUBE
Insert into the hole in the
under cover front bracket
securely.
[6] RECESS
[7] HOLE
