Settings
43
Figure 6-22 Email Setup
To configure Email notification, enter valid Email addresses as the Sender and Recipient
addresses, an Email subject, and the SMTP server address through which the Email will
be delivered. If you need to log in to SMTP server to deliver an Email, enter the User name
and password for access to that account.
Note
The Email subject and addresses can be composed of 254 characters in
numeric or alphabetic characters including: [0-9] [a-z] [A-Z] [_]
[ ][-][.][,][@]. You can enter the addresses of multiple recipients. Use
semicolons, (;), to separate the addresses of multiple recipients.
Buzzer - The buzzer is sounded on the occurrence of the event. The buzzer tones are
categorized into: Critical (1 long, 1 sec interval) Major (1 long 2 shorts, 1 sec interval),
Normal (3 shorts, 2 sec interval), Minor (2 shorts, 2 sec interval), and Notify (2 very
shorts) depending on the importance of an event. Select a Buzzer modulation from the
drop-down list.
A long tone has a duration of 1 second, while a short tone 0.5 second. A very short tone
lasts only for 0.1 second.
Select how many times the buzzer tones will be repeated on the occurrence of an event.
Figure 6-23 Buzzer Options
If events of different importance are issued at the same time, e.g., one major and one
minor event, system will ignore the minor event and sound the buzzer tone for the major
To Next Page
