4.3.8 Pen Parameters Set Up Group
Introduction
The functions in this group are used to configure the pen(s). The procedure for configuring each pen is the
same. For a 2-pen recorder, the desired input channel is displayed on the left side of the operator interface.
Press FUNC
key to select channel.
Pen group prompts
Table 4-6 lists all the function prompts in the pen set up group.
Press the SET UP
key until “PEN” appears in the lower display.
Press FUNC
key to display parameters.
Table 4-6 Pen Parameter Definitions
Lower Display
Prompt
Upper Display
Range of Setting
or Selection
Parameter
Definition
PEN IN
INP [factory setting]
REM1
REM2
OUT*
SP*
PEN INPUT—What do you want the pen to record?
INPUT—Records the input for given channel.
REMOTE SWITCH 1 EVENT—Records the digital input
event for given channel. (Event toggles pen between
90 % and 95 % on chart.)
REMOTE SWITCH 2 EVENT—Records the digital input
event for given channel. (Event toggles pen between
80 % and 85 % on chart.)
OUTPUT—Records the output for the channel.
SETPOINT—Records setpoint for given channel.
*Only selectable if hardware supports outputs and
function prompt “CONTRL” in Control group is set to
“ENAB” (enabled).
CHT HI
–999 to 9999
[factory setting = 780]
CHART HIGH RANGE VALUE—Enter a value that
corresponds with the chart high range value for
the pen. (This is the value that prints at the outer edge of
the chart. If you had a range of 0 °C to –400 °C, –400
would be the chart high range value.)
CHT LO
–999 to 9999
[factory setting = 730]
CHART RANGE LOW VALUE—Enter a value that
corresponds with the chart low range value for the
pen.
To Next Page
