Honeywell DR4311 User Manual

Appendix B - Available 10-inch Charts
4/00 DR4300 Circular Chart Recorder Product Manual 209
B.2 Dual Range Charts
Table B-2 lists the chart part numbers for the available 10-inch dual range charts.
✔ indicates the chart is used in Table 3-2 configurations.
Table B-2 10-inch Dual Range Chart Part Numbers
Calibration Range 1 Range 2 24 HR
P/N 24001660-XXX
7 DAY
P/N 24001661-XXX
Linear/Linear 0 to 15 0 to 3,000,000 200
–100 to +200 35 to 0 600 600*
0 to 200 63 to 0 602*
0 to 2000 0 to 90 633*
–18 to +94 35 to 0 603
–18 to +94 35 to 0 603
–22 to +158 0 to 10 174*
0 to 50 0 to 100 606* 606
0 to 60 0 to 100 138*
0 to 100 –30 to +70 601 ✔ 601 ✔
0 to 100 0 to 14 621*
0 to 100 –80 to +20 653* ✔
40 to 140 30 to 40 148*
50 to 150 0 to 100 097
50 to 150 20 to 0 609
50 to 150 0 to 100 097
Linear %/Linear PH 0 to 100 0 to 14 213
Linear/K T/C Deg. F 0 to 100 0 °F to 2000 °F 640*
Linear/RTD Deg. C 0 to 100 –87°C to +191 °C 145*
Linear Deg. C/Linear –40 °C to +150 °C 0 to 100 RH 660* 660*
Linear Deg. F/Linear % RH 0 °F to 120 °F 0 to 100 207
Linear Deg. C/Linear % RH –90 °C to +190 °C 0 to 100 197 ✔
Linear Deg. C/Linear –18 °C to +37 °C 0 to 100 620*
Linear Deg. F/Linear –40 °F to +300 °F 0 to 100 RH 661* 661*
Linear Deg. F/K T/C Deg. F 0 °F to 3000 °F0 °F to 2000 °F 645*
Linear Deg. F/Linear 32 °F to 122 °F 0 to 100 151*
Linear Deg. F/Linear % RH –125 °F to +375 °F 0 to 100 195 ✔ 194 ✔
Linear Deg. F/PSI Linear 0 °F to 1400 °F 0 to 5000
Linear Deg. C/Linear –18 °C to +37 °C 0 to 100 637* ✔
Linear GPM/Linear PH 0 to 100 0 to 14 214
0 to 250 0 to 14 200
