Installation
3/00 DR4300 Circular Chart Recorder Product Manual 15
2.2 Mounting Considerations and Overall Dimensions
Physical considerations
The recorder can be mounted flush in a panel or on the surface of a panel or wall using the mounting kit
supplied with the recorder. Adequate access space must be available at the back of the panel for installation
and servicing.
A kit for mounting the unit on a pipe is available (see Section 9 Parts List).
Overall dimensions
The overall dimensions and panel cutout requirements for mounting the recorder are shown in Figure 2-1.
Front View
Left Side View
Bottom View
Panel
Cutout
Surface
Mounting
355.6
14.0
320.5
12.6
355.6
14.0
322.56
12.70
322.56
12.70
147.8
5.8
320.5
12.6
17.5
0.6
369.6
14.5
196.2
7.7
181.3
7.1
163.2
6.4
24210
Rear View
41.3
1.6
Max. panel
thickness
28.6
1.125
Dimensions:
Millimetres
Inches
23
0.9
14.5
0.57
Short wing latch :
5
0.19
Double bit latch
:
Latch
Figure 2-1 Overall Dimensions
