DR4300 Circular Chart Recorder
112 DR4300 Circular Chart Recorder Product Manual 4/00
4.3.18 Remote Switch (Digital Inputs) Set Up Group
Introduction
If the hardware supports optional digital inputs, the parameters in this group are used to specify what action
the recorder will take if these “remote switches”, triggered by some external event, are closed.
Remote switch group prompts
Table 4-16 lists all the function prompts in the remote switch set up group and their definitions.
For a 2-pen recorder, the desired input channel is displayed on the left side of the operator interface.
Press FUNC
to select channel.
Press SETUP
key until “REM SW” appears in the lower display.
Press FUNC
key to select the parameters.
