C.4 Setpoint Program Prompt Hierarchy
Table C-1 lists all the function prompts for Setpoint Program data configuration in the order of their
appearance. These prompts are available when SPPROG is enabled in the SPRAMP set up group described
in Section 4.
All parameters may be changed while the program is disabled or in HOLD.
Table C-1 Prompt Hierarchy and Available Selections
Lower Display
Prompt
Upper Display
Range of Setting
or Selection
Parameter
Definition
SPPROG
DIS
ENAB
SETPOINT PROGRAMMING—This must be set to ENAB
for the setpoint program feature to work, and for the
associated operating parameters to be displayed.
SPRAMP must be disabled. (See Section 4.)
DIS—Disabled
ENAB—Enabled
START 1
1,3,5,7,9,11,13,15,17,19,
21,23 [factory setting=1]
START SEGMENT FOR PROGRAM 1—Enter the
number of the first segment in Program 1.
END 1
2,4,6,8,10,12,14,16,18,20,22
,24 [factory setting=6]
END SEGMENT FOR PROGRAM 1—Enter the number
of the last segment in Program 1.
START 2
1,3,5,7,9,11,13,15,17,19,
21,23 [factory setting=7]
START SEGMENT FOR PROGRAM 2—Enter the
number of the first segment in Program 2.
END 2
2,4,6,8,10,12,14,16,18,20,22
,24 [factory setting=12]
END SEGMENT FOR PROGRAM 2—Enter the number
of the last segment in Program 2.
START 3
1,3,5,7,9,11,13,15,17,19,
21,23 [factory setting=13]
START SEGMENT FOR PROGRAM 3—Enter the
number of the first segment in Program 3.
END 3
2,4,6,8,10,12,14,16,18,20,22
,24 [factory setting=18]
END SEGMENT FOR PROGRAM 3—Enter the number
of the last segment in Program 3.
START 4
1,3,5,7,9,11,13,15,17,19,
21,23 [factory setting=19]
START SEGMENT FOR PROGRAM 4—Enter the
number of the first segment in Program 4.
END 4
2,4,6,8,10,12,14,16,18,20,22
,24 [factory setting=24]
END SEGMENT FOR PROGRAM 4—Enter the number
of the last segment in Program 4.
RECYCL
0 to 99
[factory setting=0]
RECYCLES—Enter the number of times the program
selected for execution will be repeated.
SOKDEV
–99.9 to 99.9 engineering
units
[factory setting=0.00]
SOAK DEVIATION—Enter the acceptable deviation from
setpoint during a soak cycle. If the PV differs from the
setpoint by more than the value of SOKDEV, soak time is
frozen.
There are no guaranteed soaks if SOKDEV = 0.
