Installation
3/00
DR4300 Circular Chart R
ecorder Product Manual
19
Notch
Pan Head Screw
8-32 x 1/2
inch
Hex Head Bo
lt
1/4-20 x 3/8
inch
Hex Head Bolt
1/4-20
x 3/4 inc
h
Bracket
Side View
NOTE:
Mounting bra
c
kets an
d attaching hardw
are are inc
luded in kit 307
55065-502;
panel ga
sket supplied i
n kit 51197657-50
1.
Figure 2-4 Pa
nel Mounting Recorder with NEM
A
4 or Heavy Duty
Door
30
32
