Routine Maintenance
4/00 DR4300 Circular Chart Recorder Product Manual 159
6.3 Replacing the Ink Cartridge
Procedure
Refer to Figure 6-1 and follow the procedure in Table 6-2 to replace the ink cartridge.
Table 6-2 Procedure for Replacing the Ink Cartridge
Step Action
1
Remove the power from the recorder, then open the door.
2
Pull up on the pen lifter to raise the pen(s) from the chart plate.
ATTENTION Be careful not to move the pen arm while removing and installing the ink cartridge.
3
Unclip and remove the purple (pen 1) or red (pen 2) ink cartridge from the pen arm.
4
Remove the protective cap from the pen tip on the new cartridge and open its clip. (If you plan
to store or ship the recorder, save the protective cap.)
5
Slide the new cartridge onto the pen arm so that its tip fits into the notch at the end of the pen
arm and close the clip to secure the cartridge to the pen arm.
6
Push down the pen lifter to return the pen tip to the chart.
7
Close the door and apply power.
