4.3.19 Display Parameter Set Up Group
Introduction
Using the BLANK function, the display can be set to turn off a configured number of seconds after the last
press of any key. Pressing any key while the display is blank will restore it.
When the TOGGLE function is enabled, the pen currently driving the display will switch control to the
other pen after a configured timeout period. If the other pen has its TOGGLE function enabled, it will
switch back after its configured timeout period.
Lockout group prompts
Table 4-17 lists the function prompt in the lock out set up group.
For a 2-pen recorder, the desired input channel is displayed on the left side of the operator interface. Press
FUNC
to select channel.
Press SETUP
key until “DSPLAY” appears in the lower display.
Press FUNC
key to select the parameter.
Table 4-17 Display Parameter Definitions
Lower Display
Prompt
Upper Display
Range of Setting
or Selection
Parameter
Definition
BLANK
OFF [factory setting]
2s
4s
.
.
.
30s
BLANKING FUNCTION—Use this parameter to set
timeout period after which the display goes blank. OFF
disables the function.
TOGGLE
OFF [factory setting]
2s
4s
.
.
.
30s
TOGGLE FUNCTION—Use this parameter to set the
timeout period after which control the display is passed to
the other board (pen).
