Configuration, Startup, and Operation
of Recorder with Display
4/00 DR4300 Circular Chart Recorder Product Manual 93
Lower Display
Prompt
Upper Display
Range of Setting
or Selection
Parameter
Definition
RSTABL
NO [factory setting]
KEY
REM1*
REM2*
TOTALIZER RESETABLE—This parameter is used to
specify whether and how the totalizer value can be reset.
NO—Totalizer value cannot be reset.
KEY—Totalizer can be reset from the keypad by setting the
“RESET” parameter to “YES”.
REM1—Totalizer will be reset when remote (external) switch
(digital input 1) goes to ON (contact closure). This totalizer
reset is independent of any set up of “REMSW1” in the
remote switch set up group.
REM2—Totalizer will be reset when remote (external) switch
(digital input 2) goes to ON (contact closure). This totalizer
reset is independent of any set up of “REMSW2” in the
remote switch set up group.
CUTOFF
0 % to 100 %
LOW CUTOFF VALUE—Input % of range below which the
totalizer stops accumulating.
*Digital input card must be installed.
To Next Page
