DR4300 Circular Chart Recorder
96 DR4300 Circular Chart Recorder Product Manual 4/00
Lower Display
Prompt
Upper Display
Range of Setting
or Selection
Parameter
Definition
CTRALG
(continued)
PID A
NOTE: PID A should not be
used for proportional only
action (that is, no integral
(reset) action). Instead, use
PDMR with “RATE T” set to
0.
PROPORTIONAL-INTEGRAL-DERIVATIVE—
PID A is normally used for three-mode control. Unlike
ON/OFF control, with PID A the output can be
somewhere between 100 % and 0 %. PID A applies all
three control actions (Proportional, Integral, and
Derivative) to the error. This control can be tuned using
the parameters in the tuning group.
• Proportional (gain) regulates the controller’s output in
proportion to the size of the error (difference between
setpoint and process variable).
• Integral (reset) regulates the controller’s output in
proportion to the size of the error and time the error
has existed (duration). The amount of corrective action
depends on the value of the proportional gain.
• Derivative (rate) regulates the controller’s output in
proportion to the rate of change of the error. Again, the
amount of correction depends on the gain setting.
PDMR
PROPORTIONAL-DERIVATIVE with MANUAL
RESET—Use PDMR whenever integral action is not
needed during automatic control. The output is calculated
with no integral contribution. Then the value specified
using the tuning parameter “MANRST” (manual reset) is
added to the computed output to determine the controller
output.
Switching between manual and auto modes will not be
bumpless in PDMR.
PDMR variations: If you select PDMR you can configure
the following variations:
• PD (proportional-derivative) control, by setting
MANRST to 0.
• P (proportional only) control, by setting MANRST
(integral term) to 0 and rate (derivative term) to 0
(tuning parameter “RATE T”).
PWR UP POWER UP CONTROLLER MODE RECALL—This
selection determines which mode the recorder will use
when it restarts after a power loss.
MAN [factory setting]
MANUAL—At power-up, the recorder will use manual
mode with the output value displayed.
AUTO
AUTOMATIC—At power-up, the recorder will return to
the automatic mode.
DEFDSP
INP [factory setting]
SP
DEFAULT DISPLAY—This selection determines the
default display (input or active setpoint) on power up.
To Next Page
