Configuration, Startup, and Operation
of Recorder with Display
4/00 DR4300 Circular Chart Recorder Product Manual 107
Lower Display
Prompt
Upper Display
Range of Setting
or Selection
Parameter
Definition
A1S1HL
HI
LO [factory setting]
ALARM 1 SETPOINT 1 STATE—Select whether you
want the alarm type chosen in prompt "A1S1TY" to alarm
high or low.
HI ALARM—Relay coil is de-energized when the PV is
above the setpoint.
LO ALARM—Relay coil is de-energized when the PV is
below the setpoint.
A1S2HL
HI [factory setting]
LO
ALARM 1 SETPOINT 2 STATE—Select whether you
want the alarm type chosen in prompt "A1S2TY" to alarm
high or low.
HI ALARM—Relay coil is de-energized when the PV is
above the setpoint.
LO ALARM—Relay coil is de-energized when the PV is
below the setpoint.
A1 HYS
0.0 % to 100.0 % of input
span
[factory setting = 0]
ALARM 1 HYSTERESIS—This is an adjustable
hysteresis provided on alarm 1 that activates at exactly
the alarm setpoint when the alarm is OFF. When the
alarm is ON, it will not deactivate until the variable is
away from the alarm setpoint by a value equal to A1
HYS. Configure the hysteresis as a percent of input
range span.
A2S1TY
Same as A1S1TY
ALARM 2 SETPOINT 1 TYPE—Select what you want
Setpoint 1 of Alarm 2 to represent. The selections are the
same as “A1S1TY”.
A2S2TY
Same as A1S1TY
ALARM 2 SETPOINT 2 TYPE—Select what you want
Setpoint 2 of Alarm 2 to represent. The selections are the
same as “A1S1TY”.
A2S1VA
–999 to 9999
[factory setting = 100]
ALARM 2 SETPOINT 1 VALUE—This is the value at
which you want the alarm type chosen in prompt
"A2S1TY" to actuate. The appropriate value depends on
what the setpoint has been configured to represent.
A2S2VA
–999 to 9999
[factory setting = 100]
ALARM 2 SETPOINT 2 VALUE—This is the value at
which you want the alarm type chosen in prompt
"A2S2TY" to actuate. The appropriate value depends on
what the setpoint has been configured to represent.
A2S1HL
HI
LO [factory setting]
ALARM 2 SETPOINT 1 STATE—Select whether you
want the alarm type chosen in prompt "A2S1TY" to alarm
high or low.
HI ALARM—Relay coil is de-energized when the PV is
above the setpoint.
LO ALARM—Relay coil is de-energized when the PV is
below the setpoint.
A2S2HL
HI [factory setting]
LO
ALARM 2 SET POINT 2 STATE—Select whether you
want the alarm type chosen in prompt "A2S2TY" to alarm
high or low.
HI ALARM—Relay coil is de-energized when the PV is
above the setpoint.
LO ALARM—Relay coil is de-energized when the PV is
below the setpoint.
