Configuration, Startup, and Operation
of Recorder with Display
4/00 DR4300 Circular Chart Recorder Product Manual 127
Step Operation Press Action/Result
5
Enter the setpoint
DISP
until
Upper Display
shows the input (PV) value.
Lower Display
SP and the setpoint value for
the selected channel.
or
Adjust the setpoint to the value at which you want the
process variable maintained.
6
Select automatic
mode
MAN
AUTO
RESET
Until “A” indicator is ON.
The recorder is in Automatic mode.
The recorder will automatically adjust the output to
maintain the process variable at setpoint as tracked by
the pen trace.
7
Start up Controller
#2
FUNC
Until INP 2 indicator on left side of display is lit.
For recorders with two control outputs enabled, repeat
steps 2 to 6 for the second control output, but be sure
INP “2” indicator is lit instead of INP “1”.
8
Exit Startup Close the door and monitor the operation.
