DR4300 Circular C
hart Recorder
206
DR4300 Circular C
hart Recorder Product Manual
4/00
Chart Ty
pe
Range
Units
24 HR
P/N 24001660-XXX
7 DAY
P/N 24001661-XXX
Linear (continued)
0 to 40
110
041
0 to 45
078
0 to 50
104
✔
051
✔
0 to 55
130
0 to 70
075
✔
0 to 80
120
0 to 100
001
✔
001
✔
0 to 120
054
0 to 150
180
✔
0 to 200
010
✔
004
✔
0 to 300
050
✔
050
✔
0 to 350
037
✔
037
✔
0 to 400
011
✔
005
✔
0 to 600
052
✔
0 to 750
223
0 to 800
137
✔
0 to 1000
173
✔
0 to 1200
108
✔
0 to 1600
109
✔
0 to 2000
F
202
✔
0 to 2400
GPM
219
0 to 2500
113
✔
0 to 7000
123
0 to 8000
208
0 to 25000
111
0.2 to 2.0
176
176
1.3 to 1.8
4 to 10
177
177
5 to 9
PH
093
10 to 20
METE
R
231
20 to 120
039
039
40 to 70
125
217
219
