DR4300 Circular Chart Recorder
230 DR4300 Circular Chart Recorder Product Manual 4/00
Step Press Action/Result
Cooling Tuning
6
DISP
until you see
Lower Display
S2 nnn
Display Setpoint 2.
7
or
Until the value of Setpoint 2 is at the desired value within the
Cooling zone.
8
DISP
until you see
Lower Display
UseSP1
9
or
to toggle to.
Lower Display
UseSP2
10
DISP
until you see
Lower Display
TuneOF
11
or
to toggle to
Lower Display
TuneON
Tuning will begin and the lower display will flash
“TUNING”. The output will cycle between 0 %
and 50 % (or low output limit). When tuning has
been completed the lower display will again show
“TuneOF”. The Cool tuning parameters are
entered for the second set of PID constants in
the tuning set up group.
